Model Number:SR469-P5-HI-A20-E
Brand:General Electric
Category:Motor Management Relay
Operating Voltage:90 – 300 Volt DC, 70 – 265 Volt AC
Analog Outputs:4 x 0 to 1 mA
Digital Inputs:9 opto-isolated inputs
Current Rating:390/500 MA (MAX)
Phase Current Inputs:5A
Frequency Range:48-62 Hz
RTD Input Compatibility:100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum
Operating Temperature Range:-40°C to +60°C
Storage Temperature Range:-40°C to +80°C
Enclosure Rating:20-X
Overvoltage Category:II
Insulation Voltage:300 V
Pollution Degree:2
The GE SR469-P5-HI-A20-E is a state-of-the-art Motor Management Relay that ensures the efficient operation and protection of medium and large motors. With its advanced monitoring capabilities, it can detect and respond to potential issues before they become critical. The relay features an enhanced front panel with a larger LCD display for easy access to real-time data. Additionally, the device includes multiple RTD inputs, allowing it to determine the actual temperature and hottest point for the motor system, ensuring optimal performance and longevity. The SR469-P5-HI-A20-E is designed for harsh environments, featuring conformal coating that protects against chemical exposure and other environmental factors. With its wide voltage range and frequency compatibility, this relay is suitable for a variety of industrial applications. It is built to withstand extreme temperatures, making it a reliable choice for demanding environments. The SR469-P5-HI-A20-E also includes four analog outputs and nine opto-isolated digital inputs, providing comprehensive monitoring and control capabilities. For added convenience, it comes equipped with software that simplifies setup and configuration. Overall, the GE SR469-P5-HI-A20-E is an indispensable tool for ensuring the safe and efficient operation of industrial motors.
