Frequency Range:0.1 µHz to 120 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Resolution:14-bit vertical resolution
Output Amplitude:20 mVpp to 10 Vpp
Phase Shift:+/- 180 degrees
Bandwidth:Up to 120 MHz (-3 dB)
Memory Depth:16 kpts
Trigger Source:Internal, External, Network
Interface:USB, Ethernet, GPIB
The Tektronix 5B40 Arbitrary Function Generator is designed for engineers and researchers requiring precise control over waveform generation. It offers a comprehensive range of frequencies and waveforms, making it suitable for a variety of applications including telecommunications, aerospace, defense, and academic research.
The high-resolution vertical resolution ensures accurate waveform representation, while the wide frequency range allows users to generate signals across multiple domains. The robust memory depth enables storage of complex waveforms for advanced signal processing tasks.
The generator supports multiple trigger sources, providing flexibility in experimental setups and integration with other laboratory equipment. The interface options include USB, Ethernet, and GPIB, facilitating seamless connectivity and data transfer.
Built with durable components, the Tektronix 5B40 is designed for long-term reliability in demanding environments. Its compact design ensures easy integration into existing systems without compromising performance or functionality.
With its intuitive user interface and comprehensive documentation, the Tektronix 5B40 is user-friendly and efficient. Whether you’re conducting rigorous testing or developing cutting-edge technology, this generator provides the precision and versatility needed for success.
